Fowler Bed With Side Rails

Get a Price/Quote

Fowler Bed With Side Rails Specification

Dimension (L*W*H)
Approx. 2100 x 900 x 550 mm

Regional Style
Modern Hospital Furniture

Design
Perforated Steel Top, Easy-to-Clean and Ergonomic Design

Height
550650 mm (Adjustable)

General Use
Medical Furniture

Specific Usage
Patient Care in Hospitals, Clinics, Nursing Homes

Furniture Type
Hospital Bed

Material
Mild Steel (Frame) + ABS (Head/Foot Boards & Side Rails)

Metals Type
Powder-Coated Mild Steel

Folded
No

Function
Fowler PositionBackrest and Knee Rest Elevation, Trendelenburg and Reverse Trendelenburg

Back Rest Lifting Angle
0 80 (Adjustable)

Size
Standard Single Bed

Weight
6080 kg (Approx.)

Maximum Loading
180-200 kg

Feature
With Collapsible Side Rails, Manual Adjustment, Anti-rust finish, Heavy Duty Casters, Removable Head & Foot Boards

Head/Foot Boards
Removable, Molded ABS

Mattress Compatibility
Standard Fowler Bed Mattress

Casters/Wheels
Four 125 mm Swivel Casters with Brakes

Assembly
Knockdown construction for easy transport and assembly

Mattress Platform
Two-Section Perforated Steel

Side Rails Type
Collapsible Aluminium or ABS Side Rails

Finish
Epoxy Powder-Coated Anti-Corrosive Treatment

Safety
Secure Lock Side Rails for Patient Protection

Back Rest Adjustment Mechanism
Manual Crank System

Knee Rest Lifting Angle
0 40 (Adjustable)

About Fowler Bed With Side Rails

Fowler Bed With Side Rails

Frame Work Made Of Rectangular M.S Tube.
2 Section Top Made Of Perforated M.S Sheet.
ABS Molded.
Head & Foot Panels.
Location for I.V Rod.
Dimension: 206 x 90 x 60 cm.
Semi Fowler With Side Railing With Wheels.
Pre-treated, epoxy coated finish. Locations provided for all accessories.
Strong re-in forced, H shaped legs on rubber stumps.
Detachable/fix head & foot M.S. bows.
With Castor Wheels 2 with breaks and 2 without breaks.

Engineered for Patient Comfort and Safety

Featuring collapsible aluminium or ABS side rails with a secure lock, this Fowler Bed prioritizes patient protection while allowing convenient access for caregivers. Manual crank systems provide adjustable back and knee rest angles, supporting individualized patient positioning for various medical needs.

Durable Construction and Easy Maintenance

Built with a robust mild steel frame and anti-rust epoxy powder coating, the bed ensures longevity even in demanding hospital environments. The perforated steel mattress platform enhances ventilation, while removable head and foot boards enable straightforward cleaning and sanitation.

Smooth Mobility and Flexible Assembly

With four swivel casters equipped with brakes, this hospital bed can be moved and stabilized effortlessly. The knockdown design allows easy transportation and quick onsite assembly, making it suitable for both new facilities and upgrades in existing healthcare environments.

FAQ's of Fowler Bed With Side Rails:

Q: How do the collapsible side rails enhance patient safety on this Fowler Bed?

A: Collapsible aluminium or ABS side rails feature a secure locking mechanism, which helps prevent accidental falls and ensures patients remain safely positioned during rest or adjustment.

Q: What assembly process does the Fowler Bed require upon delivery?

A: The bed utilizes a knockdown construction, meaning it is delivered in separate parts that can be easily assembled on site without the need for specialized tools.

Q: When should the backrest or knee rest adjustments be used?

A: Adjustments are recommended to support various Fowler positions, assist in patient care activities, and improve comfort during medical procedures or extended hospital stays. The manual crank allows precise elevation of the backrest and knee rest.

Q: Where is this hospital bed best utilized?

A: This Fowler Bed is specifically suited for patient care in hospitals, clinics, nursing homes, and healthcare facilities requiring flexible, adjustable medical furniture.

Q: What are the benefits of the two-section perforated steel mattress platform?

A: The platform's perforations enhance airflow under the mattress, reducing heat and moisture buildup, which helps maintain a hygienic environment and increases patient comfort.

Q: How does the anti-corrosive coating contribute to the bed's durability?

A: The epoxy powder-coated finish creates a resilient, rust-resistant barrier on the steel frame, extending the product's lifespan and maintaining hygiene standards in medical settings.
